Hifi furniture, designed for sound and your home, Never Looked Better!
The Harbeth C7 OM 44 Custom Built Speaker Stand Range are a quadrifid design available as standard 535mm high including base isolation spikes and manufactured with ERW mild steel support columns.
The Harbeth C7 OM design includes a precision laser cut out 4mm Inert Acoustic steel top and 6mm CR4 steel base plate, when combined with zinc plated, allen key adjustable M8 base isolation spikes and M8 fixing bolts provide total joint rigidity. The hand finished, polished acoustic steel isolation plates connect to ERW BS EN 10305-3 steel 50.8 x 50.8mm tubes, as standard for sound quality and as part of the Custom Design attention to detail philosophy.
Custom Design manufacture the world renowned Inert, Acoustic Steel and Acoustic Aluminium products for total intra and inter specific isolation.
Custom Design are proud to present the new concept, open frame principle with a high mass value OM speaker stands. The OM Speaker Stands are manufacture by the craftsman at Custom Design to create a totally rigid speaker stand support with significant initial Mass. Mass loading the steel support columns with Inert Filler, adds greatly to the final mass, maximising the performance of your Harbeth Compact 7 speaker. The OM 44 Speaker Stands can be mass loaded with 1 bag of Inert Filler 1.7kg per bag into each vertical support. A box of Inert Filler with 8 bags is 13kg per box.
The modern, contemporary Harbeth Compact 7 OM ranges have true aesthetic appeal. When combined with Inert, Acoustic steel Top plates and CR4 Steel Base plates the reduction in resonance noise vibration is significant, resulting in an improved performance and sound quality. Please visit our Acoustic Steel page to view the graph demonstrating which frequencies of resonance vibration noise are absorbed by each process and the combination of Acoustic Steel top and base plates with our specially selected Inert Filler material.
Custom Design sources all cardboard packaging from only PEFC or FSC certified companies. 76% of the cardboard packaging has been manufactured from recycled material which can be 100% recycled.
Rigidity is proven integral design feature which improves sound performance. The Custom Design philosophy of multi column supports provides superior sound quality and performance over traditional single column support design speaker stands.
Custom Design do not use Aluminium in the construction of any speaker stand designs. The natural properties of aluminium prevent speaker stands from performing to the best of their ability as mechanical feedback can be prevented, just like over mass loading. Which will result in reducing the dynamic range and the depth of bass frequency.
Open Frame Medium Mass Harbeth Compact 7 OM 44 speaker stands 14kg per pair without Inert Filler
Image: Harbeth Compact 7 OM 44 Speaker Stands with a 4mm acoustic steel isolation top plate 270mm x 300mm x 535mm high including base isolation spike. Hifi Isolation Accessory 25mm dia solid aluminium floor protectors in Black set of £39.99 optional extra
Image: Harbeth Compact 7 OM 44 Speaker stands with a precision laser cut out 4mm CR4 Acoustic Steel Isolation Plate with 20mm x 20mm x 8mm isolation pads supplied as standard. Converts resonance energy to negiliable heat using a constrained layer dampening system
Image: Harbeth Compact 7 OM 44 Speaker Stands Side View in Black
Image: Harbeth Compact 7 OM 44 Speaker Stands Front View in Black
Hifi Isolation Accessory 25mm dia solid aluminium floor protectors in Black set of £39.99 optional extra
Image: Harbeth Compact 7 OM 44 Speaker Stands Side View in Black
Hifi Isolation Accessory 25mm dia solid aluminium floor protectors in Black set of £39.99 optional extra
Image: M8 Base Isolation Spike Black zinc plated with complimenting spike covers supplied as standard.
Image: Easy access allen key adjustable M8 base isolation spikes supplied as standard
Image: Harbeth Compact 7 OM 44 Speaker Stands Top View in Black
Image: Harbeth Compact 7 OM 44 Speaker Stands Side View in Black
Hifi Isolation Accessory 25mm dia solid aluminium floor protectors in Black set of £39.99 optional extra
Image: Harbeth Compact 7 OM 44 Speaker Stands Front View in Black
Hifi Isolation Accessory 25mm dia solid aluminium floor protectors in Black set of £39.99 optional extra
Image: Hifi Isolation Accessories 25mm dia solid aluminium floor protectors in Black set of 8 £39.99
Image: Inert Filler Custom Design exclusive speaker stand mass loading material, very high mass value, small particle size to kill voids inside support columns and easy to apply. 8 bags per box 13kg weight.
Harbeth C7 Speaker stands Custom Built OM Speaker Stand Support Stands are supplied as standard with a precision laser cut out, Inert, Acoustic Steel isolation Top and 6mm CR4 steel Base plates. Harbeth Compact 7 Acoustic steel isolation top Support 270mm wide x 300mm depth x 4mm Acoustic Steel Harbeth Compact 7 CR4 steel Base Plate dimensions 320mm x 350mm x 6mm CR4 M8 Black Zinc plated, Allen key Adjustable base isolation spikes supplied as standard.
Standard height available 510mm plus base isolation spike allow 25mm for the spike (535mm) Custom Heights available on request.
Standard finishes: Black
Initial Mass Harbeth Compact 7 OM 18kg per pair
Final Mass Including Inert Filler 31kg per pair (1 bag per vertical support if mass loading is required please test before)
Image: OM Harbeth Compact 7 Speaker Stands in Black - Image supplied by Input Audio Germany (Harbeth Distributor) Image: OM Harbeth Compact 7 Speaker Stands in Black
Image: Inert Filler Custom Design Specialist Mass Loading Speaker Stand Material 13kg per box 8 bags per box
Image: Hifi Isolation Accessories 25mm dia Solid Aluminium Floor protectors in Black £39.99 set of 8
Image: OM Harbeth Compact 7 Speaker Stands in Black
Image: OM Harbeth Compact 7 Speaker Stands in Black
